Radiation Shielding

Lead Bricks Cave (Interlocking Type)

Interlocking Lead Bricks make it easy to erect, modify and relocate protecve walls and caves of any size. Their V‐ shaped edges eliminate the danger of leakage, common to all straight‐edged bricks. Interlocking Lead Bricks create sturdy walls for a safe, protecve enclosure.

• Generally lead bricks are constructed in 4”x4”x2” and 4”x2”x2” sizes. Thickness 2”
• Classified into many types like, standard, base, top, corner and end brick
• Available in the form of a cave with each arm of 16”
• Total 48 bricks to make this cave
• Made of 99.99% pure (first grade) lead
• Fully painted surface for long lasng finish
• Available with a metal top cover to maintain smooth shape of cave and ease of cleaning and gives cosmec looks
• No exposure of lead to environment

Decay Drum

The Shielded Decay Drum provides safe handling and storage of radioacve waste material. The drum features a top‐loading, handled lid with a 6" x 8" drop port. Each drum includes a plasc drum placed inside.

• Round shaped structure constructed of sturdy mild steel with paint
• Height 28” from ground; diameter 16”
• Handles on sides ensure ease of handling
• Made of 99.99% pure (first grade) lead sheet
• Mounted on four sturdy wheels (two lockable) for ease of maneuvering

Available models
RH‐DD‐3 Lead Shielding 3mm; weight 80 Kg approx.
RH‐DD‐6 Lead Shielding 6mm; weight 145 Kg approx.
RH‐DD‐12 Lead Shielding 12mm; weight 260 Kg approx.
RH‐DD‐25 Lead Shielding 25mm; weight 500 Kg approx.

Waste Bin (Foot Operated)

This Shielded Waste Container is used in facilies that generate low‐energy beta and gamma radiaon waste.

• Constructed enrely of mild steel with thick paint
• Easily maneuverable foot operaon, for lesser effort
• Height 20” from ground; diameter 12”
• Mounted on four sturdy wheels (two lockable) forease of movement
• Handles on sides ensure ease of handling
• Made of 99.99% pure (first grade) lead sheet

Available models
RH‐WB‐3 Lead Shielding 3mm; weight 65 Kgapprox.
RH‐WB‐6 Lead Shielding 6mm; weight 120 Kg approx.
RH‐WB‐12 Lead Shielding 12mm; weight 230 Kg approx.
RH‐WB‐25 Lead Shielding 25mm; weight 450 Kg approx.

Syringe Carrier

Shielded Syringe Carriers reduce exposure while storing or transporng radioacve material. Large handle for ease of carrying.

Constructed enrely of mild steel with thick painted surface and large handle Dimensions :10” (length), 5” (width) and 4” (height). SS 304 model also available

Available models:
• Lead shielding 6mm on all walls; weight 6 Kg approx.
• Lead shielding 15mm on all walls; weight 12 Kg approx.

Lead Pots

Designed to handle variety of radioacve materials within the department. Can be custom designed to any dimension, shape, lead thickness. Appropriate lid on the top for shielding and ease of carrying. Constructed of mild steel exteriors with thick painted surface. With or without lid handle and screwed cap.

Standard Models
▪ 6” height, 2” ID and 0.5” lead shielding; weight 18 Kg approx.
▪ 6” height, 2” ID and 1” lead shielding; weight 35 Kg approx.
▪ 6” height, 3” ID and 0.5” lead shielding; weight 20 Kg approx.
▪ 6” height, 3” ID and 1” lead shielding; weight 38 Kg approx.

'L' Bench

For Handling Unit Doses of High‐Energy Radionuclides Designed for receiving and preparing unit doses of high‐energy radionuclides, these L‐Blocks provide a choice of size and lead thickness. An oponal Lead Brick Cave may be added to provide lateral shielding around the full perimeter of the L‐Block's base.

Constructed of mild steel with thick layer of paint. Made from a connuous layer of 99.99% pure (first grade) lead sheet. No porosity for radiaon leakage. Fied with lead glass of appropriate thickness. Supplied with a 5W LED light for beer visibility.

Size : Base 18”x12”, vercal wall 18”x12”, tapered wall 18”x14” at 45^°
Lead glass :8”x8” window with variable thicknesses

Available standard models :
▪ RH‐LB‐2 Lead shielding 2mm with 10mm lead glass; weight 18 Kg approx.
▪ RH‐LB‐3 Lead shielding 3mm with 10mm lead glass; weight 22 Kg approx.
▪ RH‐LB‐5 Lead shielding 5mm with 25mm lead glass; weight 34 Kg approx.
▪ RH‐LB‐6 Lead shielding 6mm with 30mm lead glass; weight 40 Kg approx.
▪ RH‐LB‐12 Lead shielding 12mm with 50mm lead glass; weight 80 Kg approx.
▪ RH‐LB‐25‐PET ‐ Lead shielding 25mmBase, 40mm Front with 100mm;
Single piece lead glass window; weight 155 Kg approx.

PET Unit Dose Cabinet

Designed for PET hot labs with limited space to help maximize the work area and the protecon. The cabinet includes the RH‐LB‐25‐PET L Bench, built‐in Dose Calibrator shield and Waste bin.

Dimensions:
▪ Table Top: 36” long, 24” wide, 36” from ground
▪ L‐Bench RH‐LB‐25‐PET ‐ Lead shielding 25mm Base, 40mm Front with 100mm lead glass window
▪ Support arm to place Dose Calibrator near L Bench
▪ Dose Calibrator and Dispensing boxes are not part of supply
▪ Approx weight 650 Kg; including table, two well shields and L Bench
▪ Lead Lined Well shield; 1” thick, 12” height, 9” dia; one below the table and one inside the L Bench Lockable Cabinet

Lead-Lined Storage Safe

Conveniently loaded from the front, this Storage Safe is ideal for storing large quanes of high acvity radioisotopes. Shielded with a thickness of 2" of lead. The lead‐lined door is hung with heavy duty non‐sagging hinges and is key‐locked to prevent unauthorized access.

Transporng this half‐ton safe is made easier with the built‐in liing handles on top, for use with a hoist or other means.
▪ Dimensions: 17" w x 17" depth x 19" h (I.D.: 12" w x 12" depth x 12" h)
▪ Lead Shielding: 2" thick (5 cm)
▪ Weight: 500 kg approx.

Mobile Lead Barrier

The Adjustable Height Mobile Radiaon Shield puts shielding where it is needed. Roll into place, secure the wheels and adjust to the desired height. Panel can be height adjusted within a 6" range. Wheel and swivel locks on each caster provide secure placement. Mild steelConstrucon with rich paint surface.

▪ Dimensions: Shield: 36" w x 24" h; 60” from ground;
Height Adjustment: 6" ▪ Lead Shielding: 1" thick (2.5 cm)
▪ Finish: Pint
▪ Weight: 200 kg approx.
▪ Fixed height Lead Barrier with similar dimensions also available

Syringe Holder

Designed to hold unshielded syringes. Constructed of lead shielding, encased in mild steel. Metal flap to securely hold the syringe.

▪ Dimensions: 6.5" height, 1” dia
▪ Lead Shielding: 0.5" thick
▪ Weight: 4 Kg approx.

Syringe Recapper

The Syringe Recapper is a safe and inexpensive way to protect yourself when recapping a used syringe. Used either hand‐held or placed on a flat surface, such as a procedure tray, the Recapper is made of a lightweight plasc that is easily carried anywhere. Dimensions : 4”x4” base

Veinlite LED

• Portable& avoid mulple needle prick
• No treatment delays & reduces paents discomfort
• Improves site selecon by idenfying vein bifurcaon
• Avoid vein punctures by highlighng exact angle of veinpuncture
• Applicaon: Obese/Dark skin paents. Agitated & restless paents. Thalassemia paents. Hemophiliapaents. Renal failure paents. Mulorgan failure paents Carcinoma paents. geriatrics paents Pediatric paents

Injection Resting Chair

A Comfortable Rest between Injecon and Imaging
Most protocols require that prior to imaging, a paent rest for up to one hour aer an injecon of FDG F‐18. Typical injecon chairs are not designed for comfort, making rest difficult.

The Injecon/Resng Chair is a comfortable resng spot for paents to wait between injecon and imaging. The chair achieves recline posions and features an infinitely adjustable back and a comfortable arm rest.

Lead Shielded Refrigerator

Single Door Refrigerator with a capacity of 45 Leters designed to accommodate large qualies of Radiopharmaceucals, Tagged Biologicals and other Radioacve materials in fully shielded condions.

• Refrigerator dimensions : 46x46x80(h) cm
• Lead shielding : 6mm. 52x52x100(h) cm
• External ports for power supply and water drain L

Decontamination Kit

Decontaminaon Kit contains all the equipment needed to cope with a radioacve spill or roune decontaminaon problem in the laboratory. The drum serves as a container for the kit components and as a waste transfer/storage vessel.

• Stainless Steel Drum – 1
• Shoe Covers – 100
• Gloves – 100
• Respirators with Filters – 2
• Radiacwash liquid – 2 liters
• Radiacwash Spray Bole (empty) – 1
• Absorbent Paper Roll with stand – 1
• Area Demarcaon Tape – 1 roll
• Polybags – 30
• 12” Niptong – 1
• Sponge, Mop, Scrubber, Pail, Rope, Assorted Sign – 1 each

Dose Drawing System

The Dose Drawing System is used to draw FDG F‐18 doses from a vial. It consists of a specially designed Dose Drawing Syringe Shield, vial shield and stand. When drawing FDG F‐18, the vial shield and syringe shield remain on the stand. The stand allows the vial shield to rotate and has a fixed stop at the 45‐degree downward angle. The vial shield is constructed of 1" lead encased in steel. The shield's top is threaded to allow quick inseron and removal of vials. The top cover incorporates a pivong shield for septum access that allows the use of a vent needle, if desired, along with the needle from a 5 cc syringe.

The tungsten syringe shield mounts on a stainless steel rotang plaorm that slides the syringe into the vial and locks in posion. The dose can then be drawn with forceps to minimize hand exposure. The syringe shield is constructed of .55" tungsten. A high‐density lead glass window allows viewing up to the 5 cc mark on a 5 cc syringe.

The PET Dose Drawing System provides a safe and shielded environment while making it easy to draw a FDG F‐18 dose.
